Image may not exactly match the product.

Cisco

Cisco Catalyst 3850-32XS-S - Switch - L3 - Managed - 24 X 1 Gigabit / 10 Gigabit SFP+ + 6 X 10 Gigabit SFP+ (uplink) - Desktop, Rack-mountable - Refurbished - WS-C3850-32XS-S-RF

SKU:
WS-C3850-32XS-S-RF
Shipping:
Calculated at Checkout
$30,781.14 $19,432.13
(You save $11,349.01 )

Image may not exactly match the product.

$30,781.14 $19,432.13
(You save $11,349.01 )
Availability:
This product is currently only available for pre-order

Condition:
Refurbished
Warranty Information
Limited Warranty - advance parts replacement - lifetime - response time: next business day
Installation Type:
Desktop, Rack-mountable
Device Type:
Switch
Product Line:
Cisco Catalyst
Model:
3850-32XS-S
Family:
10 Gigabit Ethernet
Ports Qty:
32
Managed:
Yes
Stackability:
Stackable
View More

RESERVE YOURS - SHIPPING SOON! Expected Lead Time to Ship from Cisco is 28 Days!

warning
Currently available for Pre-Order only

Check details for availability or request a quote

Done shopping? You can create a PDF of your cart for later or for your purchasing dept! Details at checkout.

Hear What Our Customers Are Saying

slide 6 to 10 of 50
  • Cisco StackWise-480 technology provides scalability and resiliency with 480 Gbps of stack throughput
  • Cisco StackPower technology provides power stacking among stack members for power redundancy
  • Dual redundant, modular power supplies and three modular fans providing redundancy
  • Full IEEE 802.3at (PoE+) with 30 W power on all copper ports in 1 rack unit (RU) form factor
  • Cisco UPOE with 60 W power per port in 1 rack unit (RU) form factor

The Cisco Catalyst 3850 series is the next generation of enterprise-class stackable Ethernet and Multigigabit Ethernet access and aggregation layer switches that provide full convergence between wired and wireless on a single platform. Cisco's Unified Access Data Plane (UADP) application-specific integrated circuit (ASIC) powers the switch and enables uniform wired-wireless policy enforcement, application visibility, flexibility and application optimization. This convergence is built on the resilience of the improved Cisco StackWise-480 technology. The Cisco Catalyst 3850 series Switches support full IEEE 802.3at Power over Ethernet Plus (PoE+), Cisco Universal Power over Ethernet (Cisco UPOE), modular and field-replaceable network modules, RJ45 and fiber-based downlink interfaces, and redundant fans and power supplies. With speeds that reach 10 Gbps, the Cisco Catalyst 3850 Multigigabit Ethernet Switches support current and next-generation wireless speeds and standards (including 802.11ac Wave 2) on existing cabling infrastructure.
Product Description Cisco Catalyst 3850-32XS-S - switch - 32 ports - managed - rack-mountable
Device Type Switch - 32 ports - L3 - managed - stackable
Enclosure Type Rack-mountable 1U
Subtype 10 Gigabit Ethernet
Ports 24 x 1 Gigabit / 10 Gigabit SFP+ + 6 x 10 Gigabit SFP+ (uplink)
Performance Switching capacity: 640 Gbps
Stacking bandwidth: 480 Gbps
Capacity IPv4 routes: 24000
NetFlow entries: 48000
Virtual interfaces (VLANs): 4000
Switched virtual interfaces (SVIs): 1000
MAC Address Table Size 32000 entries
Jumbo Frame Support 9198 bytes
Routing Protocol IS-IS, RIP-1, RIP-2, IGMPv2, IGMP, IGMPv3, policy-based routing (PBR), RIPng, MLDv2, MLD
Remote Management Protocol SNMP 1, RMON 1, RMON 2, Telnet, SNMP 3, SNMP 2c, TFTP, SSH, CLI
Features DHCP support, ARP support, Syslog support, PIM snooping, MSTP support, DHCP snooping, DTP support, PAgP support, TFTP support, ACL support, QoS, SSH support, VRF-Lite, UDLD, Rapid PVST+, SRR, LACP, RSPAN, Energy Efficient Ethernet, VRF, Cisco StackWise-480 technology, Cisco StackPower technology, FNF, 802.1x authentication, RRM, ARP inspection, WTD, VTP, BPDU, CoPP
Compliant Standards IEEE 802.3z, IEEE 802.1D, IEEE 802.1Q, IEEE 802.1p, IEEE 802.3x, IEEE 802.3ad (LACP), IEEE 802.1w, IEEE 802.1x, IEEE 802.1s
Power AC 120/230 V (50/60 Hz)
Power Redundancy Optional
Dimensions (WxDxH) 17.5 in x 17.7 in x 1.8 in
Weight 13.45 lbs
Pricing Type Refurbished
Manufacturer Warranty Limited lifetime warranty
General
Device Type Switch - 32 ports - L3 - managed - stackable
Enclosure Type Desktop, rack-mountable 1U
Subtype 10 Gigabit Ethernet
Ports 24 x 1 Gigabit / 10 Gigabit SFP+ + 6 x 10 Gigabit SFP+ (uplink)
Performance Switching capacity: 640 Gbps
Stacking bandwidth: 480 Gbps
Capacity IPv4 routes: 24000
NetFlow entries: 48000
Virtual interfaces (VLANs): 4000
Switched virtual interfaces (SVIs): 1000
MAC Address Table Size 32000 entries
Jumbo Frame Support 9198 bytes
Routing Protocol IS-IS, RIP-1, RIP-2, IGMPv2, IGMP, IGMPv3, policy-based routing (PBR), RIPng, MLDv2, MLD
Remote Management Protocol SNMP 1, RMON 1, RMON 2, Telnet, SNMP 3, SNMP 2c, TFTP, SSH, CLI
Authentication Method Kerberos, Secure Shell (SSH), RADIUS, TACACS+
Features DHCP support, ARP support, Syslog support, PIM snooping, MSTP support, DHCP snooping, DTP support, PAgP support, TFTP support, ACL support, QoS, SSH support, VRF-Lite, UDLD, Rapid PVST+, SRR, LACP, RSPAN, Energy Efficient Ethernet, VRF, Cisco StackWise-480 technology, Cisco StackPower technology, FNF, 802.1x authentication, RRM, ARP inspection, WTD, VTP, BPDU, CoPP
Compliant Standards IEEE 802.3z, IEEE 802.1D, IEEE 802.1Q, IEEE 802.1p, IEEE 802.3x, IEEE 802.3ad (LACP), IEEE 802.1w, IEEE 802.1x, IEEE 802.1s
RAM 4 GB
Flash Memory 4 GB
Status Indicators Port transmission speed, port duplex mode, power, system, active, status
Expansion / Connectivity
Interfaces 24 x 10GBase-X SFP+
6 x 10GBase-X SFP+ uplink
1 x USB Type A
1 x management (mini-USB) Type B
1 x console RJ-45 management
1 x management (Gigabit LAN) RJ-45
2 x network stack device
Expansion Slots 1 (total) / 0 (free) x expansion slot
Power
Power Device Internal power supply
Installed Qty 1
Max Supported Qty 2
Power Redundancy Optional
Power Redundancy Scheme 1+1 (with optional power supply)
Power Provided 715 Watt
Voltage Required AC 120/230 V (50/60 Hz)
Miscellaneous
MTBF 307.99 hours
Compliant Standards CISPR 22 Class A, CISPR 24, EN 61000-3-2, NOM, EN 61000-3-3, EN55024, EN50082-1, EN 61000-6-1, EN 61000-4-4, EN 61000-4-2, EN 61000-4-3, EN 61000-4-6, CCC, ICES-003 Class A, EN 61000-4-5, FCC CFR47 Part 15, UL 60950-1, IEC 60950-1, EN 60950-1, UL 60950-1 Second Edition, KCC, RoHS, FCC Part 15 A, AS/NZS 3548 Class A, BSMI Class A, EN 60950-1 Second Edition, IEC 60950-1 Second Edition, VCCI Class A, KN24, KN22 Class A, AS/NZS CISPR 22, CNS 13438, EN 55022 Class A, EN 300 386, CAN/CSA-C22.2 No. 60950-1
Pricing Type Refurbished
Software / System Requirements
Software Included Cisco IOS IP Base
Dimensions & Weight
Width 17.5 in
Depth 17.7 in
Height 1.8 in
Weight 13.45 lbs
Manufacturer Warranty
Service & Support Limited warranty - advance parts replacement - lifetime - response time: next business day
Technical support - consulting - 90 days
Environmental Parameters
Min Operating Temperature 23 °F
Max Operating Temperature 113 °F
Humidity Range Operating 10 - 95% (non-condensing)
Min Storage Temperature -40 °F
Max Storage Temperature 158 °F

Specs Overview

Detailed Specs
