Tripp Lite

Tripp Lite 5-Port Unmanaged Industrial Gigabit Ethernet Switch - 10/100/1000 Mbps, Ruggedized, -40� To 75�C, EIP QoS, DIN/Wall Mount - Switch - Unmanaged - 5 X 10/100/1000 - DIN Rail Mountable, Wall-mountable - TAA Compliant - NGI-U05E

SKU:
NGI-U05E
Shipping:
Calculated at Checkout
$230.00 $129.44
(You save $100.56 )

Image may not exactly match the product.

$230.00 $129.44
(You save $100.56 )
In Stock
In-Stock
Availability:
In Stock. Ships Same Business Day If Ordered Before 3pm PT

Condition:
New
Warranty Information
Limited Warranty - 3 years
Installation Type:
DIN rail mountable, Wall-mountable
Device Type:
Switch
Product Line:
Tripp Lite
Model:
5-Port Unmanaged Industrial Gigabit Ethernet Switch - 10/100/1000 Mbps, Ruggedized, -40� to 75�C, EIP QoS, DIN/Wall Mount
Ports Qty:
5
Managed:
No
View More

Done shopping? You can create a PDF of your cart for later or for your purchasing dept! Details at checkout.

Hear What Our Customers Are Saying

slide 6 to 10 of 50
  • 5 auto-negotiable 10/100/1000 Mbps RJ45 ports connect devices over a LAN
  • EIP QoS control mechanism, widely used for Ethernet/IP data stream
  • Industrial-grade switch supports operating temperature range of -40� to 75�C
  • Easy-to-read LEDs indicate connection and activity status for all Ethernet ports
  • This product is covered by a 3-year limited warranty

This space-saving switch with EIP QoS transmits data over a Gigabit Ethernet network. Five auto-negotiating 10/100/1000 Mbps ports send data only to the devices designated to receive it, which improves the efficiency and potential throughput of the network.
The EIP QoS control mechanism is widely used for Ethernet/IP data streams. Based on the application requirements, this feature helps provide different priorities for different users or data streams. This helps ensure that the performance of data streams deliver at a certain level.
The compact NGI-U05E adds 10/100/1000 Mbps Gigabit Ethernet capacity to your industrial and commercial applications, such as factory floors, warehouse operations and other environments with space constraints and wide temperature ranges. The industrial-grade high-strength case withstands vibration, shock and free fall. It can also operate in extreme temperatures ranging from -40 to 75 degrees Celsius (-40 to 167 degrees Fahrenheit).
Quickly connect your network devices with little to no configuration. LEDs indicate when the switch is powered on and which Ethernet ports are showing activity. The NGI-U05E supports MAC address auto-learning and auto-aging for efficient routing, as well as automatic MDI/MDI-X crossover detection for plug-and-play functionality. IEEE 802.3x flow control allows smooth transmission of large files.
The NGI-U05E is browser-based and works independently from the connected computer's operating system. Because switch compatibility is based on common hardware standards, rather than system software dependencies, the NGI-U05E accommodates most platforms. Preferred web browsers include Google Chrome and Microsoft Edge.
The open-type device may be DIN mounted using the pre-installed rail clip, which mounts firmly to any standard 35 mm DIN rail. It may also be wall mounted vertically or horizontally using the rear mounting holes. A 3-pin 12-48VDC terminal block supplies power input. Device power must be supplied by SELV circuit.
The NGI-U05E is compliant with the Federal Trade Agreements Act (TAA), which makes it eligible for GSA (General Services Administration) Schedule and other federal procurement contracts.
Product Description Eaton Tripp Lite series 5-Port Unmanaged Industrial Gigabit Ethernet Switch - 10/100/1000 Mbps, Ruggedized, -40° to 75°C, EIP QoS, DIN/Wall Mount - switch - 5 ports - unmanaged - TAA Compliant
Device Type Switch - 5 ports - unmanaged
Ports 5 x 10/100/1000
Performance Switching capacity: 1 Gbps
MAC Address Table Size 2000 entries
Jumbo Frame Support 9000 bytes
Features Flow control, auto-negotiation, auto-uplink (auto MDI/MDI-X), QoS, rugged, metal housing, MAC address auto-learning
Compliant Standards IEEE 802.3, IEEE 802.3u, IEEE 802.3x
Power DC 12 - 48 V
Dimensions (WxDxH) 0.9 in x 2.9 in x 4.3 in
Weight 6.7 oz
Color Black
TAA Compliant Yes
Manufacturer Warranty 3-year warranty
Designed For P/N: N001-050-BK, N002-010-BK, N002-015-GY, N002-025-BK, N002-050-BK, N200-025-BK, N200-050-BK
General
Device Type Switch - 5 ports - unmanaged
Enclosure Type DIN rail mountable, wall-mountable
Ports 5 x 10/100/1000
Performance Switching capacity: 1 Gbps
MAC Address Table Size 2000 entries
Jumbo Frame Support 9000 bytes
Features Flow control, auto-negotiation, auto-uplink (auto MDI/MDI-X), QoS, rugged, metal housing, MAC address auto-learning
Compliant Standards IEEE 802.3, IEEE 802.3u, IEEE 802.3x
Status Indicators Power, transmit, receive, LAN
Expansion / Connectivity
Interfaces 5 x 10/100/1000 Base-T RJ-45
Power
Voltage Required DC 12 - 48 V
Power Consumption Operational 3 Watt
Miscellaneous
Color Black
Included Accessories Wall mount brackets, DIN-rail clip
Compliant Standards RoHS, REACH, IEEE 802.3, IEEE 802.3u, IEEE 802.3x, FCC (USA)
TAA Compliant Yes
Dimensions & Weight
Width 0.9 in
Depth 2.9 in
Height 4.3 in
Weight 6.7 oz
Dimensions & Weight (Shipping)
Shipping Width 5 in
Shipping Depth 9.3 in
Shipping Height 2.4 in
Shipping Weight 10.93 oz
Manufacturer Warranty
Service & Support Limited warranty - 3 years
Environmental Parameters
Min Operating Temperature -40 °F
Max Operating Temperature 167 °F
Humidity Range Operating 5 - 95% (non-condensing)
Min Storage Temperature -40 °F
Max Storage Temperature 185 °F
Compatibility Information
Designed For P/N: N001-050-BK, N002-010-BK, N002-015-GY, N002-025-BK, N002-050-BK, N200-025-BK, N200-050-BK
